TUFF WINCH

TUFF-400 Drum Anchor Winch

TUFF-400 Drum Anchor Winch

The TUFF-400 is our most powerful drum winch, engineered for serious vessels up to 12 meters that demand maximum capacity and strength. With a massive 400mm drum holding 200 meters of 12mm rope and a 3000W motor, this winch handles the scale of anchoring that larger vessels require. Whether you're running a charter operation, commercial fishing vessel, or large recreational boat, manual anchoring at this scale destroys your body and eats your time. The TUFF-400 lets one person control the entire anchoring process with a wireless remote from the helm. No crew needed, no back strain, no limitations on where you can anchor or how deep you can go.

Regular price $3,200.00 AUD
Regular price Sale price $3,200.00 AUD
Sale Sold out
DC Motor Voltage

Product Details

Anchor Solo. Protect Your Back. Get On With Your Day.

The backbreaking work of manual anchoring keeps too many boaters tied to the dock or dependent on crew. The TUFF-400 ends that. Drop and retrieve your anchor with a wireless remote from up to 20 meters away, or use the rocker switch for instant control at the bow. One person can handle the entire anchoring process in seconds, not minutes of exhausting chain hauling.

Why Australian Boaters Choose the TUFF-400

Our Most Powerful Winch for Larger Vessels

The TUFF-400 is built for boats up to 12 meters where size and weight demand serious anchoring power. The massive 400mm drum holds 200 meters of 12mm double braid rope, giving you the capacity for deep water anchoring, extended scope, and the flexibility to handle any anchoring situation. The 3000W Italian motor delivers twice the power of our mid-range models, making it the perfect match for charter boats, commercial vessels, and large recreational craft that need the muscle to handle heavier ground tackle and deeper waters.

Built to Survive Saltwater

Every component is engineered for Australian marine conditions. The 100% Australian-made 316 stainless steel drum (8mm thick with machined beveled edges) won't corrode. Oversized stainless steel bearings and 6061-T6 alloy bearing caps are sealed and built to last. This winch handles up to 200m of 12mm double braid nylon rope plus 8m of galvanized chain, with a holding capacity of 3000 kg.

Italian Power Transmission, No Maintenance Headaches

The oversized anodized worm drive gearbox with stainless steel hub and fixtures is pre-filled with synthetic oil and fully sealed. The IP66-rated 3000W 4-brush DC motor is epoxy-coated and designed to get wet. No aluminum sleeves that let water in. This transmission system is marine-graded, oversized, and built to deliver the exceptional torque and reliability that larger vessels demand.

Install Once, Anchor Anywhere

16 mounting positions mean you can position the TUFF-400 exactly where you need it on your larger vessel. The complete rounded transmission design makes installation straightforward even in complex anchor well configurations. Connect to your main battery or dual-battery setup and you're ready to go. The system integrates seamlessly with your existing electrical setup.

5-Year Warranty Guarantee

We hand-build every TUFF-400 in Queensland and back it with a 5-year in-house warranty. Over 10,000 Australian boaters trust TUFF WINCH for their anchoring systems, and for good reason.

Stop Wrestling With Your Anchor. Start Enjoying Your Boat.

The TUFF-400 gives you the freedom to operate solo, anchor with precision from the helm, and avoid the physical punishment that comes with manually handling heavy ground tackle on a large vessel. Whether you're running charters, commercial fishing, or cruising serious distances in a large recreational boat, you deserve an anchoring system that matches the capability and scale of your vessel without demanding a full crew to operate it.

What's Included?

  • TUFF-400 Drum Anchor Winch (Australian Made)
  • 8mm 316 SS Base Plate (Australian made and customized for TUFF WINCH)
  • Solenoid: 400AMP
  • Marine Grade Circuit Breaker
  • 316SS Switch Panel (Custom made for TUFF WINCH)
  • All Necessary 316 Stainless Steel nuts, bolts and washers
  • 5 Year Warranty (Direct with manufacturer not through third parties)
  • Installation diagram(s)

Features + Technical Specs

  • Italian 3000w IP66 epoxy-coated 4 brush motor - TUFF Exclusive (Full water-protection compliant with the International Protection Regulation Certified IEC/EN 60529)
  • Manufactured and Designed in Australia
  • Italian Anodised Worm Drive Gearbox with stainless steel hubs and fixtures - TUFF Exclusive (Marine graded + oversized)
  • Solid 316SS Machined 25mm Spool Shaft
  • Super Durable 8mm 316SS Plate Covering Entire Unit
  • Holds up to 200m of 12mm double braid rope + 8m of galvanized chain
  • 316SS Twin Shaft Bearing Design - (Oversized)
  • 16 Adjustable Mounting Positions (Position the motor to suit your setup)
  • 3000kg Holding Capacity
  • Machined Bevelled Edges - TUFF Exclusive (Preserves longevity of your rope)
  • Machined Bearing Cover T6061 -T6 - (Fully Sealed)
  • 30+ years experience in the power transmission industry (no other winch manufacturer has this level of experience)
  • 400MM Drum Diameter
  • Suits vessels up to 12 meters
  • Wireless remote range: Up to 100m
  • 5 Year Warranty
View full details

Power & Reliability for Any Anchor Well Setup.

Anchoring a 12-meter boat manually means hauling 200 meters of heavy rope and chain by hand. It's exhausting, time-consuming, and keeps you from enjoying your time on the water. The TUFF-400 handles the heavy lifting so you don't have to. Control everything from the helm with a wireless remote. Drop and retrieve anchor in seconds, not the 20 minutes of back-breaking work. Spend more time fishing, relaxing, and exploring, less time recovering from anchoring.

This Drum Winch Features:
400MM Drum Diameter Suits Boats Up To 12m Holds Up To 200m Of 12mm Double Braid Nylon Rope 16 Adjustable Mounting Positions
Power & Reliability for Any Anchor Well Setup.
Trusted by 1605+ Aussie Boaters

Built TUFF To Last

Engineered with high-quality 316 Stainless Steel materials for reliable performance and longevity in harsh Aussie marine environments.

Your answers to the most

Frequently Asked Questions

What battery setup do I need?

Our winches run off your main battery supply or a dual setup, so it has versatile suitability to whatever battery arrangement you prefer.

Why are your motors black not stainless?

That's an intentional choice, we utilise an oversized epoxy-coated 4 brush motor on every drum winch for true efficiency and a longer lifespan. Others use aluminium sleeves which put your motor at risk of water ingress or corrosion over time.

Do you offer free fall?

We don't have a free fall feature as standard with our winches are it sacrifices the structural integrity of the unit. They are driven up-down with switches and are very quick however we can customise your winch for this feature if you wish upon request.

How do I activate the warranty?

Your 5 year warranty begins after purchase and you can be rest assured that we backup our warranties in-house with large quantities of any and all components you may need down the track.

Are they easy to install?

Our drum winches are very easy to self install. They can be integrated with any new setup or current setup you may have and both our full kits and standalone units include the core electrical components to get you started. Following along our installation sheet is simple and we have a contact number for you to get support at anytime during installation if you run into any issues.

Where do your reviews come from?

Our reviews are verified TUFF WINCH customers and sourced from our public eBay profile, Google Business profiles and our Website. The majority comes from our eBay profile which has over 1500+ positive reviews which we have accumulated over 14+ years of selling on the platform.
